24-336970 (24-248129) Bilstein B8 5100 Series Ride Height Adjustable Shocks for 2015-2020 Ford F-150

24-336970 (24-248129) Bilstein B8 5100 Series Ride Height Adjustable Shocks for 2015-2020 Ford F-150

Bilstein B8 5100 (Ride Height Adjustable) shock absorbers are designed for trucks and SUVs with a front OE coilover style suspension. Multiple snap-ring grooves in the body allow for different spring seat positions, providing 0-3 inches of front lift with OE springs (depending on application). The monotube shock absorbers feature a 46mm digressive piston a with self-adjusting deflective disc valve setting.  Bilstein B8 5100 (Ride Height Adjustable) shock absorbers provide increased wheel travel and improved handling. Utilizing a B8 5100 (Ride Height Adjustable) shock absorber is the easiest way to level out your vehicle.

Fitment:

2015-2020 Ford F-150

Fitment Notes:

4WD Only; Front Lift Height: 0-2.5"

• Front Bilstein Shock Absorber
• Collapsed Length: 16.91"
• Extended Length: 22.41"
• Lower Mount: Cross Bar
• Upper Mount: Stem
• Travel: 5.50"
• 46mm Zinc Plated Montube Design
• Snap Ring Grooved Body Coilover
• Replacement Mounting Kit: B-KT01-0000068
• Replacement Spring Seat: E-FT01-0000005
• UPC 651860943244
• Old Bilstein Part Number: 24-248129
• Limited Lifetime Warranty
• Free Shipping in the Lower 48 United States
• Sold Individually
